Power distributor up to 400A. Box AR 19" format

Power Distributor for connecting and distributing power inputs and outputs, under the Low voltage Directive 2014/35/UE. Norm UNE/EN 61439-1.

Rack power distro with three-phase CEE plug, power meter and 24 numbered breakers
  • Designed as per request for power, connectors, protections
Connectors
With the necessary connectors in each case.
Location
Portable or Rack screw mounting.
Format
19″ AR box
Manufactured
In Spain by Pinanson S.L.

Construction

Formats

Box AR 19"

Materials and dimensions
Position
Rack screw mounting
Connection
Perpendicular to the rack
Front panel
Extruded aluminium
Rear Panel
Extruded aluminium
Union parts
Aluminium 3 mm and/or carbon steel 1.5 mm
Finish
Electrostatic powder coating 100-150 µm. Colour and direct print with text, logos, etc. on request
Dimensions mm (W X H)
1RU (483 × 44,5)
Dimensions mm (W X H)
2RU (483 × 89)
Dimensions mm (W X H)
3RU (483 × 133,5)
Dimensions mm (W X H)
4RU (483 × 177,8)
Dimensions mm (W X H)
6RU (483 × 265,9)
Dimensions mm (D)
UNI (44)
Dimensions mm (D)
AR1 (91)
Dimensions mm (D)
MAM (210)

Flight case

Flight case (Briefcase)
