Splitter audio MIC & LINE. Module.
| Mic-Line level audio splitter for distributing several channels with galvanic isolation. | |
| Features | High quality transformers. |
| Transformer | Lundahl |
| Outputs | 2 XLRM |
| Connectors | XLR |
| No. Channels | 4, 6 or 8 |
| Place | Rack screw mounting |
| Format | Box AR 19'' |
| Manufactured | In Spain by Pinanson S.L. |
RELATED BLOG POSTS
- AUDIO SIGNALS ON STAGE, FREQUENTLY ASKED QUESTIONS
- OPERA HOUSES AROUND THE WORLD
- AUDIO DISTRIBUTORS, WITH OR WITHOUT TRANSFORMERS?
REAL-WORLD PRODUCT USE CASES
Download available technical data here
Some options
Channels* 4 Channels6 Channels8 Channels
| Signal: | Mic/line level audio |
| Distribution: | Passive |
| Isolation: | By transformer. Each channel. |
| No. Input: | 1 Balanced XLR-F. Line Level. |
| Direct Output: | 1 Balanced XLR-M. (Phantom or Link) |
| No. Outputs: | 2 Balanced XLR-M. Micro/line level. |
| No. Channels: | 4, 6 or 8 |
| Frequency response: | ± 0.1 dB (-57 dBu, 20Hz-20KHz) |
| THD+N: | ≤ 0.01% (-57 dBu, 1KHz) |
| CMRR: | > 100 dB (-57 dBu, 1KHz) |
| Format: | AR 19" box |
| Name: | Box AR 19" | |
| Position: | Rack screw mounting | |
| Connection: | Perpendicular to the rack | |
| Material | Frontal Panel: | Extruded aluminium |
| Rear Panel: | Extruded aluminium | |
| Union parts | Aluminio 3mm and/or Carbon steel 1,5mm | |
| Finish: | Powder electrostatic covering 100-150 μ. Colour and direct print with text, logos, etc. on request | |
| Dimensions mm (W X H): | 1RU (483 X 44,5) | |
| 2RU (483 X 89) | ||
| 3RU (483 X 133,5) | ||
| 4RU (483 X 177,8) | ||
| 6RU (483 X 265,9) | ||
| Dimensions mm (D): | UNI (44) | |
| AR1 (91) | ||
| MAM (210) |
