SPP
| Line level audio Press Splitter for passive distributing. | |
| Features | Isolated outputs by transformer. |
| Outputs | Up to 24 XLRM |
| Transformer | Lundahl |
| Place | Portable, rack screw mounting or surface screw mounting. |
| Format | Flight case (Briefcase), Box AR 19”, Box MF, Box WR or Wall frame |
| Manufactured | In Spain by Pinanson S.L. |
RELATED BLOG POSTS
Download available technical data here
Some options
Outputs* 8 Outputs12 Outputs24 Outputs
Format* Box AR 19"Floor BoxWall rack surface boxWall frameFlight case (Briefcase)Box MF
How we have customized this product for other clients
Torrecárdenas University Hospital (Spain)
Line level audio splitter for passive distribution. For 12 press stations in briefcase-type flight case format.
Valencia Football Club (Spain)
Line level audio splitter for passive distribution. For 12 press stations in Wall Rack format.
Catalonia Hotels Resorts (Spain)
Line level audio splitter for passive distribution. For 8 press stations in surface box MF format.
Municipality of Valladolid (Spain)
Line level audio splitter for passive distribution. For 8 press stations in Wall plate format.
| Abbreviation: | SPP |
| Signal: | Line level audio |
| Distribution: | Passive |
| Isolation: | By transformer. Each channel. |
| No. Input: | 1 Balanced XLR-F. Line Level. |
| Output link: | 1 Balanced XLR-M. Line Level. |
| No. Outputs: | 8, 12 or 24 Balanced XLR-M. Line level. |
| Frequency response: | ± 0.8 dB (+4 dBu, 20Hz-20KHz) |
| THD+N: | ≤ 0.05% (+4 dBu, 1KHz) |
| CMRR: | > 100 dB (+4 dBu, 1KHz) |
| Format: | Fly case (Briefcase), Wall Rack or MF box |
FORMAT Flight case (Briefcase)
| Name: | Flight case (Briefcase) | |
| Position: | Surfaces | |
| Installation: | Mobile | |
| Material: | Hinges and locking: | Galvanized sheet |
| Handle: | Plastic | |
| Corners: | Plastic (MOD: ALUM) or Galvanized sheet (MOD: ALUM-W 2015) | |
| Frames: | Aluminium | |
| Foot: | Rubber | |
| Surface: | Plywood and exterior face covered with 4mm (MOD: ALUM) or 6mm PVC (MOD: ALUM-W 2015) | |
| Inner coating: | Foam 5mm (ALUM-W 2015) | |
| Connection panel: | Extruded aluminium | |
| Finish: | Inside finish: | Powder electrostatic covering 100-150 μ. Colour on request. Direct print with text, logos, etc. on request. |
| Acronym: | M |
| Name: | Box AR 19" | |
| Position: | Rack screw mounting | |
| Connection: | Perpendicular to the rack | |
| Material | Frontal Panel: | Extruded aluminium |
| Rear Panel: | Extruded aluminium | |
| Union parts | Aluminio 3mm and/or Carbon steel 1,5mm | |
| Finish: | Powder electrostatic covering 100-150 μ. Colour and direct print with text, logos, etc. on request | |
| Dimensions mm (W X H): | 1RU (483 X 44,5) | |
| 2RU (483 X 89) | ||
| 3RU (483 X 133,5) | ||
| 4RU (483 X 177,8) | ||
| 6RU (483 X 265,9) | ||
| Dimensions mm (D): | UNI (44) | |
| AR1 (91) | ||
| MAM (210) |
| Name | Box MF A | Box MF S | Box MF PD | |
| Position: | Surfaces | Surfaces | Surfaces | |
| Installation: | Mobile | Screw mounting | Screw mounting | |
| Connection: | Perpendicular to the surface | Perpendicular or parallel to the surface (connectors on the lateral lids) | Perpendicular to the surface | |
| Material: | Box: | Extruded aluminium | Extruded aluminium | Extruded aluminium |
| Covers: | Aluminum 3mm | Steel 1,5mm | Aluminum plate | |
| Finish: | Powder electrostatic covering 100-150 μ. Colour and direct print with text, logos, etc. on request. | Powder electrostatic covering 100-150 μ. Colour and direct print with text, logos, etc. on request. | Powder electrostatic covering 100-150 μ. Colour and direct print with text, logos, etc. on request. | |
| Acronym: | CAM A | CAM S | CAM PD | |
| Dimensions mm (W X H X D): | CAM A (Depends on the configuration X 115 X 45) | CAM S (Depends on configuration X 115 X 45) | CAM PD (115 X 45 X Depends on configuration) | |
| CAMG A (Depends on the configuration X 143 X 47) | CAMG S (Depends on configuration X 143 X 47) | CAMG PD (143 X 47 X Depends on configuration) |
| Name | Box WR | |
| Position: | Surface | |
| Installation: | Screw mounting | |
| Connection: | Perpendicular to the surface | |
| Material: | Flap: | Steel 1,5mm |
| Door: | ||
| Box: | Steel 1,5mm | |
| Connection panel: | Extruded aluminium | |
| Finish: | Powder electrostatic covering 100-150 μ. Colour and direct print with text, logos, etc. on request. | |
| Acronym: | WR | |
| Dimensions mm (W X H X D): | 2RUMM (137 X 146 X 100) | |
| 2RUM (273 X 143 X 70/100) | ||
| 4RUM (273 X 300 X 70/100) | ||
| 6RUM (273 X 300 X 70/100) | ||
| 8RUM (273 X 389 X 70/100) | ||
| 2RU (515 X 143 X 70/100) | ||
| 4RU (515 X 300 X 70/100) | ||
| 6RU (515 X 300 X 70/100) | ||
| 8RU (515 X 480 X 70/100) | ||
| 10RU (515 X 480 X 70/100) | ||
| 12RU (515 X 655 X 70/100) | ||
| 14RU (515 X 655 X 70/100) |
| Name: | W Wall frame | |
| Position: | Surface | |
| Installation: | Built-In | |
| Connection: | Perpendicular to the surface | |
| Material: | Wall frame: | Steel 1,5mm |
| Door: | ||
| Back box: | ||
| Connection panel: | Extruded aluminium | |
| Finish: | Powder electrostatic covering 100-150 μ. Colour and direct print with text, logos, etc. on request. | |
| Acronym: | W | |
| Dimensions mm (W X H X D): | 2RUM (273 X 143 X 8) | |
| 4RUM (273 X 300 X 8) | ||
| 6RUM (273 X 300 X 8) | ||
| 8RUM (273 X 389 X 8) | ||
| 2RU (515 X 143 X 8) | ||
| 4RU (515 X 300 X 8) | ||
| 6RU (515 X 300 X 8) | ||
| 8RU (515 X 480 X 8) | ||
| 10RU (515 X 480 X 8) | ||
| 12RU (515 X 655 X 8) | ||
| 14RU (515 X 655 X 8) |
| Name: | Box TB AT | |
| Position: | Floor | |
| Installation: | Built-in | |
| Connection: | Perpendicular to the floor | |
| Material: | Flap: | 6mm aluminum plate |
| Door: | 6mm aluminum plate | |
| Door axis: | Inox steel | |
| Axis support: | Nickel-plated brass | |
| Cable exit hinges: | Inox steel | |
| Frontal and rear panel: | Extruded aluminium | |
| Connection panel: | Extruded aluminium | |
| Union laterals: | Aluminum plate | |
| Finish: | Outside finish: | Powder electrostatic covering 100-150 μ. |
| Inside finish: | Powder electrostatic covering 100-150 μ. Colour on request. Direct print with text, logos, etc. on request. | |
| Maximum supported Load (By compression test at 20 ± 3° C, 10 mm/min): | 12.670 N | |
| Acronym: | TB AT | |
| Dimensions mm (W X H X D): | 2U 183 (183 X 180 X 134) | |
| 2U 233 (233 X 180 X 134) | ||
| 3U 233 (233 X 255 X 134) | ||
| 4U 300 (300 X 270 X 178) |
